Standard

Broadband over powerline

Carrier Frequencies

2MHz ~ 30MHz

Communication Technique

OFDM

AC Input Voltage

AC 100V ~ 277V

AC Output

Voltage: AC 100V ~ 277V, Current: AC 4 Amp (Max)

PWM Dimming

Cable: Brown (+), Black (-)
Frequency: 200Hz ~ 8KHz
Duty Cycle: 10 % ~ 100 %, 10 steps

1~10V Dimming

Cable: Red (+), Black (-) Voltage: 1 ~ 10V, 10 steps

Meter

Voltage Measurement: 100V ~ 277V ± 1 %

Current Measurement: <0.3A ± 20mA  , >0.3A ± 1 %

Frequency Measurement: 50/60 Hz ± 1 %

Power Factor Measurement: -0.95 ~ 1 ± 1 %

Power Measurement: ± 2 % (depending on Power Factor)

Accumulated Energy Measurement: Wh (per hour)

Power Consumption

5 Watt (Max)

Operating Temperature

-40 ℃ ~ 60 ℃

Humidity

10 % ~ 95 %

Dimensions (L × W × H)

13 cm x 8 cm x 3.8 cm (with Mounting Flange)
