Key Characteristics

Capacity

up to 1 Gbps with HC

up to 472 Mbps at 56 MHz 1024 QAM

up to 474 Mbps at 60 MHz 1024 QAM

Frequency bands

11GHz, 15GHz, 17GHz UL, 18GHz, 23GHz, 24GHz UL, 25GHz, 26GHz, 38GHz, 42GHz and more*

Modulation

From 4QAM up to 1024QAM with hitless ACM

Channel Bandwidth

ETSI

from 3.5 MHz up to 56 MHz

FCC

from 5 MHz up to 60 MHz

Configurations

1+0, 2+0 link bonding

Gigabit Ethernet

1xRJ-45, 2xSFP

Management

In-band and Out of band

SNMP v1/2c/3, SSH, Telnet, HTTPS, Serial, RADIUS, Network Time Protocol

Antenna

Integrated antenna

Form factor

Size 0.3m w/o mount 378x378x227 mm; <5kg

Size 0.6m w/o mount 669x669x289 mm; <5kg

Size 1ft w/o mount 14.9x14.9x9.0 inch; <11lbs

Size 2ft w/o mount 26.3x26.3x11.4 inch; <11lbs

Temperature range

-33 ... +55 °C / -28 … +130 °F
