PN

J0SSAP10

J0SSAP11

J0SSAP12

J0SSAP13

J0SSAP14

Frequency bands

2.4/2.5/3.6/4.9/5/6/7/8 GHz

6/7/8/10/11 GHz

10/11/13/15/17 GHz

17/18/23/24 GHz

24/26/30/32/38 GHz

Frequency range

2.000 - 8.000

5.925 - 12.000 GHz

10.000 - 18.000 GHz

17.000 - 24.300 GHz

24.000 - 40.000

GHz

GHz

Input power range

 -105 dBm to -40 dBm

-100 dBm to -40 dBm

Max input power

 0 dBm

0 dBm

RBW (Resolution bandwidth)

 1 MHz

1 MHz

Span

 100 MHz

100 MHz

to full bandwidth

to full bandwidth

Sweep speed

 0.5s @ 100MHz Span

0.5s @ 100MHz Span

Guaranteed accuracy

 +/- 3dB

+/- 3dB

Input

 50 ohm SMA (f)

50 ohm 2.92 mm (f)

Interface

 mini USB 2.0 (1.1)

mini USB 2.0 (1.1)

LED indication

 when charging

when charging

Battery

 2380 mAh

2 x 2380 mAh

Polymer Lithium-ion

Polymer Lithium-ion

Battery life

 up to 4h

up to 3h

Operating temperature

 -15°C to +55°C/

-15°C to +55°C/

5°F to 131°F

5°F to 131°F
